Polyester PP base scrim
High performance technical fabrics for PVC coated and Laminated vinyls
Warp knit, weft insertion base scrim
| Spec | Type | Width (max) | Spec | Type | Width (max) |
|---|---|---|---|---|---|
| P250x250x68 (18x18) | X & Z | 245" (622cm) | P1000x1000x68 (4.5x4.5) | I2 | 182" (462cm) |
| P250x500x68 (18x12) | X & Z | 245" (622cm) | P1000x1000x68 (6x6) | ATRAS | 245" (622cm) |
| P420x500x68 (16x16) | Z | 182" (462cm) | P1000x1000x68 (12x12) | X & Z | 176" (447cm) |
| P420x630x68 (16x10) | Z | 182" (462cm) | P1300x1300x68 (9x9) | X & Z | 245" (622cm) |
| P420x1000x68 (16x9) | Z | 182" (462cm) | P1500x1500x68 (12x12) | Z | 182" (462cm) |
| P500x500x50 (9x9) | X & Z | 245" (622cm) | P2000x2000x68 (9x9) | Z | 245" (622cm) |
| P840x840x50 (9x9) | X & Z | 245" (622cm) | P1000x1000x68 (16x16) | X & Z | 160" (406cm) |
| P1000x1000x50 (9x9) | X & Z | 245" (622cm) | P1000x1000x50 (18x16) | I2 | 160" (406cm) |
| P1000x1000x68 (3x3) | I2 | 182" (462cm) | Geo Grid | 4T, 6T, 8T, 10T, 15T, 20T | |
Woven base scrim
| Spec | Width (max) | Spec | Width (max) |
|---|---|---|---|
| P250 (17x17) | 87" (220cm) | P1000 (20x20) | 136" (345cm) |
| P250 (22x23) | 87" (220cm) | P1000 (23x23) | 136" (345cm) |
| P420 (17x18) | 87" (220cm) | P1000 (28x26) | 136" (345cm) |
| P630 (17x18) | 87" (220cm) | P1300 (18x18) | 136" (345cm) |
| P840 (14x14) | 87" (220cm) | P1500 (14x14) | 91" (230cm) |
| P1000 (14x14) | 136" (345cm) | P3000 (7x7) | 91" (230cm) |
| P1000 (16x16) | 136" (345cm) | N840 (46x46) | 136" (345cm) |
| P1000 (18x18) | 136" (345cm) | SP1200 (18x18) | 136" (345cm) |
